LT5400BCMS8E-4#TRPBF Specifications

• Series:LT5400
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Circuit Type:Isolated
• Resistance (Ohms):1k
• Tolerance:±15%
• Number of Resistors:4
• Resistor Matching Ratio:±0.025%
• Resistor-Ratio-Drift:±0.2ppm/°C
• Number of Pins:8
• Power Per Element:800mW
• Temperature Coefficient:±25ppm/°C
• Operating Temperature:0°C ~ 70°C
• Applications:Voltage Divider (TCR Matched)
• Mounting Type:Surface Mount
• Package / Case:8-TSSOP, 8-MSOP (0.118", 3.00mm Width) Exposed Pad
• Supplier Device Package:8-MSOP-EP
• Size / Dimension:0.118" L x 0.118" W (3.00mm x 3.00mm)
• Height - Seated (Max):0.043" (1.10mm)
