EEF-CS0J680R Specifications

• Series:SP-Cap CS
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Type:Polymer
• Capacitance:68 µF
• Tolerance:±20%
• Voltage - Rated:6.3 V
• ESR (Equivalent Series Resistance):15mOhm
• Lifetime @ Temp.:2000 Hrs @ 105°C
• Operating Temperature:-55°C ~ 105°C
• Ratings:-
• Applications:General Purpose
• Ripple Current @ Low Frequency:-
• Ripple Current @ High Frequency:5.1 A @ 100 kHz
• Impedance:-
• Lead Spacing:-
• Size / Dimension:0.287" L x 0.169" W (7.30mm x 4.30mm)
• Height - Seated (Max):0.047" (1.20mm)
• Surface Mount Land Size:0.287" L x 0.169" W (7.30mm x 4.30mm)
• Mounting Type:Surface Mount
• Package / Case:2917 (7343 Metric)
