WLS27XWGRYB5-0570DS24Q Specifications

• Series:WLS27
• Package:Box
• Part Status:Active
• Type:LED Module
• Color:Red, Green, Blue, Yellow, White
• CCT (K):5000K
• Wavelength:525nm Green, 625nm Red, 470nm Blue, 580nm Yellow
• Configuration:Linear Light Strip
• Luminous Flux @ Current/Temperature:370lm Red, 800lm Green, 250lm Blue, 1140lm Yellow, 1300lm White
• Current - Test:630mA
• Temperature - Test:25°C
• Voltage - Forward (Vf) (Typ):24V
• Lumens/Watt @ Current - Test:24 lm/W Red, 53 lm/W Green, 17 lm/W Blue, 75 lm/W Yellow, 86 lm/W White
• Current - Max:800mA
• CRI (Color Rendering Index):-
• Viewing Angle:-
• Features:IP66, IP67, IP69K
• Size / Dimension:27.00mm Dia
• Height:633.50mm
• Light Emitting Surface (LES):-
• Lens Type:Flat
