WLS28-2XWGRYB5-0850X24Q Specifications

• Series:WLS28-2
• Package:Box
• Part Status:Active
• Type:LED Module
• Color:Blue, Green, Red, White, Yellow
• CCT (K):5000K
• Wavelength:470nm Blue, 525nm Green, 625nm Red, 580nm Yellow
• Configuration:Linear Light Strip
• Luminous Flux @ Current/Temperature:-
• Current - Test:945mA
• Temperature - Test:25°C
• Voltage - Forward (Vf) (Typ):24V
• Lumens/Watt @ Current - Test:17 lm/W Blue, 53 lm/W Green, 24 lm/W Red, 86 lm/W White, 89 lm/W Yellow
• Current - Max:1.2A
• CRI (Color Rendering Index):-
• Viewing Angle:-
• Features:IP50
• Size / Dimension:891.00mm L x 28.00mm W
• Height:21.00mm
• Light Emitting Surface (LES):-
• Lens Type:Flat
