SWI5-5-N-P5 Specifications

• Series:SWI5-N (5W)
• Package:Box
• Part Status:Active
• Region Utilized:North America
• Form:Wall Mount (Class II)
• Input Type:Fixed Blade
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:5V
• Current - Output (Max):1A
• Power (Watts):5 W
• No Load Power Consumption:75mW (Max)
• Polarization:Positive Center
• Applications:ITE (Commercial)
• Efficiency:Level VI, CoC Tier 2
• Operating Temperature:0°C ~ 40°C
• Output Connector:Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm
• Cord Length:59" (1.50m)
• Input Connector:NEMA 1-15P
• Size / Dimension:0.89" L x 1.42" W x 1.88" H (22.6mm x 36.0mm x 47.7mm)
• Approval Agency:CSA, FCC, PSE, UL
• Standard Number:C22.2 No. 60950-1; 60950-1; 62368-1
