SWI18-5-N-P5 Specifications

• Series:SWI18-N (18W)
• Package:Box
• Part Status:Active
• Region Utilized:North America
• Form:Wall Mount (Class II)
• Input Type:Fixed Blade
• Voltage - Input:90 ~ 264 VAC
• Voltage - Output:5V
• Current - Output (Max):3A
• Power (Watts):15 W
• No Load Power Consumption:100mW (Max)
• Polarization:Positive Center
• Applications:ITE (Commercial)
• Efficiency:Level VI
• Operating Temperature:0°C ~ 40°C
• Output Connector:Barrel Plug, 2.1mm I.D. x 5.5mm O.D. x 9.5mm
• Cord Length:59" (1.50m)
• Input Connector:NEMA 1-15P
• Size / Dimension:2.83" L x 1.34" W x 2.05" H (72.0mm x 34.0mm x 52.0mm)
• Approval Agency:CB Scheme, CCC, CSA, FCC, IEC, PSE, UL
• Standard Number:C22.2 No. 60950-1; 60950-1; 62368-1
