DRP024V060W1AA Specifications

• Series:CliQ (60W)
• Package:Box
• Part Status:Active
• Type:Enclosed, Conformal Coated
• Number of Outputs:1
• Voltage - Input:85 ~ 264 VAC
• Voltage - Output 1:24V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):2.5A
• Power (Watts):60W
• Applications:ITE (Commercial)
• Voltage - Isolation:4 kV
• Efficiency:87%
• Operating Temperature:-20°C ~ 75°C (With Derating)
• Features:Adjustable Output, DC Input Capable, Load Sharing, Universal Input
• Mounting Type:DIN Rail
• Size / Dimension:4.72" L x 1.26" W x 4.76" H (120.0mm x 32.0mm x 121.0mm)
• Approval Agency:ATEX EN, CB Scheme, CE, CSA, DNV GL, EAC, EN, SEMI, SIQ, UL
• Standard Number:107.1-01; 213, 12.12.09; 508; 50581; 55011; 55024; 55032; 60079-15; 60950-1; 61000-3-2; 61000-6-1; 61000-6-2; 61204-3; 62368-1
