FPS100048/S Specifications

• Series:FPS1000 (1000W)
• Package:Bulk
• Part Status:Active
• Type:Front End
• Number of Outputs:1
• Voltage - Input:85 ~ 265 VAC, 120 ~ 360 VDC
• Voltage - Output 1:48V
• Voltage - Output 2:-
• Voltage - Output 3:-
• Voltage - Output 4:-
• Current - Output (Max):21A
• Power (Watts):1008W
• Applications:ITE (Commercial)
• Voltage - Isolation:3 kV
• Efficiency:88%
• Operating Temperature:0°C ~ 60°C (With Derating)
• Features:Adjustable Output, Hot Swappable, I²C™ Interface, Load Sharing, PFC, Remote Sense, Standby Output, Universal Input
• Mounting Type:Rack Mount
• Size / Dimension:11.42" L x 5.00" W x 1.61" H (290.0mm x 127.0mm x 41.0mm)
• Approval Agency:-
• Standard Number:-
