HLG-80H-24B Specifications

• Series:HLG-80H (80W)
• Package:Box
• Part Status:Active
• Type:Constant Current, Voltage
• Topology:AC DC Converter
• Number of Outputs:1
• Voltage - Input (Min):90VAC
• Voltage - Input (Max):305VAC
• Voltage - Output:14.4 ~ 24V
• Current - Output (Max):3.4A
• Power (Watts):82 W
• Voltage - Isolation:3.75 kV
• Dimming:Analog, PWM
• Features:OCP, OTP, OVP, SCP
• Ratings:IP67
• Operating Temperature:-40°C ~ 80°C
• Efficiency:90.5%
• Termination Style:Wire Leads
• Size / Dimension:6.76" L x 2.42" W x 1.53" H (171.8mm x 61.5mm x 38.8mm)
• Approval Agency:CB, CCC, CE, cULus, cURus, PSE, RCM, TUV, UL
• Standard Number:-
