MF-MSHT020KX-2

Image is for reference, please contact us to get the real picture

Manufacturer Part
MF-MSHT020KX-2
Manufacturer
J.W. Miller / Bourns
Description
1812 HIGH TEMP SMD POLYMER PTC 0
Category
Circuit Protection Devices
Family
PTC Resettable Fuses
Series
-
In Stock
2000
Datasheets
-

MF-MSHT020KX-2 Specifications

  • Series:Multifuse® MF-MSHT
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:Polymeric
  • Voltage - Max:42V
  • Current - Max:40 A
  • Current - Hold (Ih) (Max):200 mA
  • Current - Trip (It):1 A
  • Time to Trip:100 ms
  • Resistance - Initial (Ri) (Min):500 mOhms
  • Resistance - Post Trip (R1) (Max):4.5 Ohms
  • Resistance - 25°C (Typ):-
  • Operating Temperature:-40°C ~ 125°C
  • Ratings:AEC-Q200
  • Mounting Type:Surface Mount
  • Package / Case:1812 (4532 Metric), Concave
  • Size / Dimension:0.181" L x 0.128" W (4.60mm x 3.24mm)
  • Height - Seated (Max):-
  • Thickness (Max):0.033" (0.85mm)
  • Lead Spacing:-
