MF-NSMF020-2

Image is for reference, please contact us to get the real picture

Manufacturer Part
MF-NSMF020-2
Manufacturer
J.W. Miller / Bourns
Description
PTC RESET FUSE 24V 200MA 1206
Category
Circuit Protection Devices
Family
PTC Resettable Fuses
Series
-
In Stock
4045
Datasheets
-

MF-NSMF020-2 Specifications

  • Series:Multifuse®, MF-NSMF
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Type:Polymeric
  • Voltage - Max:24V
  • Current - Max:10 A
  • Current - Hold (Ih) (Max):200 mA
  • Current - Trip (It):460 mA
  • Time to Trip:600 ms
  • Resistance - Initial (Ri) (Min):600 mOhms
  • Resistance - Post Trip (R1) (Max):2.6 Ohms
  • Resistance - 25°C (Typ):-
  • Operating Temperature:-40°C ~ 85°C
  • Ratings:AEC-Q200
  • Mounting Type:Surface Mount
  • Package / Case:1206 (3216 Metric), Concave
  • Size / Dimension:0.126" L x 0.063" W (3.20mm x 1.60mm)
  • Height - Seated (Max):-
  • Thickness (Max):0.033" (0.85mm)
  • Lead Spacing:-
