HEV2AN-P-DC12V

Image is for reference, please contact us to get the real picture

Manufacturer Part
HEV2AN-P-DC12V
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE DPST 20A 12V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
49
Datasheets
-

HEV2AN-P-DC12V Specifications

  • Series:HE-V
  • Package:Tray
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:12VDC
  • Contact Form:DPST-NO (2 Form A)
  • Contact Rating (Current):20 A
  • Switching Voltage:1000VDC - Max
  • Coil Current:160 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Flux Protection
  • Coil Insulation:Class F
  • Must Operate Voltage:8.4 VDC
  • Must Release Voltage:0.6 VDC
  • Operate Time:30 ms
  • Release Time:10 ms
  • Operating Temperature:-40°C ~ 55°C
  • Contact Material:Silver Nickel (AgNi)
  • Relay Type:General Purpose
