8690120000

Image is for reference, please contact us to get the real picture

Manufacturer Part
8690120000
Manufacturer
Weidmuller
Description
RELAY GEN PURPOSE 4PDT 6A 24V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
17
Datasheets
-

8690120000 Specifications

  • Series:RCM
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Socketable
  • Coil Voltage:24VAC
  • Contact Form:4PDT (4 Form C)
  • Contact Rating (Current):6 A
  • Switching Voltage:240VAC - Max
  • Coil Current:41.6 mA
  • Coil Type:Non Latching
  • Features:Lighted Indicator, Test Button
  • Termination Style:Plug In, Quick Connect - 0.110" (2.8mm)
  • Seal Rating:-
  • Coil Insulation:-
  • Must Operate Voltage:19.2 VAC
  • Must Release Voltage:7.2 VAC
  • Operate Time:15 ms
  • Release Time:10 ms
  • Operating Temperature:-40°C ~ 70°C
  • Contact Material:Silver Nickel (AgNi)
  • Relay Type:General Purpose
