AZ2280-1A-277AEF

Image is for reference, please contact us to get the real picture

Manufacturer Part
AZ2280-1A-277AEF
Manufacturer
American Zettler
Description
40A MINIATURE POWER RELAY
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
110
Datasheets
-

AZ2280-1A-277AEF Specifications

  • Series:-
  • Package:Tray
  • Part Status:Active
  • Mounting Type:Chassis Mount
  • Coil Voltage:277VAC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):40 A
  • Switching Voltage:277VAC, 28VDC - Max
  • Coil Current:18.5 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:Quick Connect - 0.187"/0.250"
  • Seal Rating:Sealed - Fully
  • Coil Insulation:Class F
  • Must Operate Voltage:235.4 VAC
  • Must Release Voltage:55.4 VAC
  • Operate Time:15 ms
  • Release Time:10 ms
  • Operating Temperature:-55°C ~ 60°C
  • Contact Material:Silver Cadmium Oxide (AgCdO)
  • Relay Type:General Purpose
