ALF1P12

Image is for reference, please contact us to get the real picture

Manufacturer Part
ALF1P12
Manufacturer
Panasonic
Description
RELAY GEN PURPOSE SPST 20A 12V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
2037
Datasheets
-

ALF1P12 Specifications

  • Series:ALF
  • Package:Box
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:12VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):20 A
  • Switching Voltage:250VAC - Max
  • Coil Current:75 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:-
  • Coil Insulation:-
  • Must Operate Voltage:8.4 VDC
  • Must Release Voltage:1.2 VDC
  • Operate Time:20 ms
  • Release Time:15 ms
  • Operating Temperature:-40°C ~ 60°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
