T9AS1D22-24

Image is for reference, please contact us to get the real picture

Manufacturer Part
T9AS1D22-24
Manufacturer
TE Connectivity Potter & Brumfield Relays
Description
RELAY GEN PURPOSE SPST 30A 24V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
1360
Datasheets
-

T9AS1D22-24 Specifications

  • Series:T9A
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:24VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):30 A
  • Switching Voltage:277VAC - Max
  • Coil Current:41.7 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin, Quick Connect - 0.250" (6.3mm)
  • Seal Rating:Sealed - Fully
  • Coil Insulation:Class F
  • Must Operate Voltage:18 VDC
  • Must Release Voltage:2.4 VDC
  • Operate Time:15 ms
  • Release Time:15 ms
  • Operating Temperature:-55°C ~ 85°C
  • Contact Material:Silver Cadmium Oxide (AgCdO)
  • Relay Type:General Purpose
