T9GS1L14-24

Image is for reference, please contact us to get the real picture

Manufacturer Part
T9GS1L14-24
Manufacturer
TE Connectivity Potter & Brumfield Relays
Description
RELAY GEN PURPOSE SPST 30A 24V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
1488
Datasheets
-

T9GS1L14-24 Specifications

  • Series:T9G
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:24VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):30 A
  • Switching Voltage:480VAC - Max
  • Coil Current:37.5 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Fully
  • Coil Insulation:Class F
  • Must Operate Voltage:18 VDC
  • Must Release Voltage:2.4 VDC
  • Operate Time:15 ms
  • Release Time:22 ms
  • Operating Temperature:-40°C ~ 105°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
