SDT-S-109LMR2,000

Image is for reference, please contact us to get the real picture

Manufacturer Part
SDT-S-109LMR2,000
Manufacturer
TE Connectivity Potter & Brumfield Relays
Description
RELAY GEN PURPOSE SPST 5A 9V
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
22
Datasheets
-

SDT-S-109LMR2,000 Specifications

  • Series:SDT-R, OEG
  • Package:Tube
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:9VDC
  • Contact Form:SPST-NO (1 Form A)
  • Contact Rating (Current):5 A
  • Switching Voltage:250VAC, 30VDC - Max
  • Coil Current:16.7 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:-
  • Coil Insulation:Class E
  • Must Operate Voltage:6.75 VDC
  • Must Release Voltage:0.9 VDC
  • Operate Time:15 ms
  • Release Time:5 ms
  • Operating Temperature:-30°C ~ 70°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
