AZ943-1CH-12DE

Image is for reference, please contact us to get the real picture

Manufacturer Part
AZ943-1CH-12DE
Manufacturer
American Zettler
Description
15A SUGAR CUBE RELAY
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
347
Datasheets
-

AZ943-1CH-12DE Specifications

  • Series:-
  • Package:Tray
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:12VDC
  • Contact Form:SPDT (1 Form C)
  • Contact Rating (Current):10 A
  • Switching Voltage:277VAC, 30VDC - Max
  • Coil Current:30 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Fully
  • Coil Insulation:Class B
  • Must Operate Voltage:9 VDC
  • Must Release Voltage:1.2 VDC
  • Operate Time:10 ms
  • Release Time:5 ms
  • Operating Temperature:-40°C ~ 90°C
  • Contact Material:Silver Tin Oxide (AgSnO)
  • Relay Type:General Purpose
