AZ2850-2C-12DE

Image is for reference, please contact us to get the real picture

Manufacturer Part
AZ2850-2C-12DE
Manufacturer
American Zettler
Description
40A MINIATURE POWER RELAY
Category
Relays
Family
Power Relays, Over 2 Amps
Series
-
In Stock
60
Datasheets
-

AZ2850-2C-12DE Specifications

  • Series:-
  • Package:Tray
  • Part Status:Active
  • Mounting Type:Through Hole
  • Coil Voltage:12VDC
  • Contact Form:DPDT (2 Form C)
  • Contact Rating (Current):3 A
  • Switching Voltage:600VAC, 30VDC - Max
  • Coil Current:140 mA
  • Coil Type:Non Latching
  • Features:-
  • Termination Style:PC Pin
  • Seal Rating:Sealed - Fully
  • Coil Insulation:Class F
  • Must Operate Voltage:9 VDC
  • Must Release Voltage:1.2 VDC
  • Operate Time:25 ms
  • Release Time:25 ms
  • Operating Temperature:-40°C ~ 85°C
  • Contact Material:Silver Cadmium Oxide (AgCdO)
  • Relay Type:Solar
