M2015TJW01-GC-2A-C

Image is for reference, please contact us to get the real picture

Manufacturer Part
M2015TJW01-GC-2A-C
Manufacturer
NKK Switches
Description
SWITCH ROCKER SPDT 6A 125V
Category
Switches
Family
Rocker Switches
Series
-
In Stock
912
Datasheets
-

M2015TJW01-GC-2A-C Specifications

  • Series:M
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Panel Mount, Snap-In
  • Circuit:SPDT
  • Switch Function:On-Mom
  • Current Rating (Amps):6A (AC), 3A (DC)
  • Voltage Rating - AC:125 V
  • Voltage Rating - DC:30 V
  • Actuator Type:Paddle - Illuminated
  • Color - Actuator/Cap:Red
  • Actuator Marking:No Marking
  • Illumination Type, Color:LED, Red
  • Illumination Voltage (Nominal):2.8 VDC
  • Termination Style:Solder Lug
  • Ingress Protection:-
  • Features:Epoxy Sealed Terminals
  • Panel Cutout Dimensions:Rectangular - 15.90mm x 12.50mm
  • Operating Temperature:-30°C ~ 85°C
