3MN1

Image is for reference, please contact us to get the real picture

Manufacturer Part
3MN1
Manufacturer
Honeywell Sensing and Productivity Solutions
Description
SWITCH SNAP ACTION SPDT 15A 120V
Category
Switches
Family
Snap Action, Limit Switches
Series
-
In Stock
42
Datasheets
-

3MN1 Specifications

  • Series:MN
  • Package:Bulk
  • Part Status:Active
  • Circuit:SPDT (DB/DM)
  • Switch Function:On-Mom
  • Current Rating (Amps):15A (AC), 800mA (DC)
  • Voltage Rating - AC:120 V
  • Voltage Rating - DC:115 V
  • Actuator Type:Round (Pin Plunger)
  • Mounting Type:Chassis Mount
  • Termination Style:Screw Terminal
  • Ingress Protection:-
  • Features:-
  • Operating Force:340 ~ 567gf
  • Release Force:170gf
  • Pretravel:0.060" (1.5mm)
  • Differential Travel:0.025" (0.6mm)
  • Overtravel:0.080" (2.03mm)
  • Operating Temperature:-55°C ~ 85°C
