M2022LL3G03

Image is for reference, please contact us to get the real picture

Manufacturer Part
M2022LL3G03
Manufacturer
NKK Switches
Description
SWITCH TOGGLE DPDT 0.4VA 28V
Category
Switches
Family
Toggle Switches
Series
-
In Stock
13
Datasheets
-

M2022LL3G03 Specifications

  • Series:M
  • Package:Bulk
  • Part Status:Active
  • Mounting Type:Panel Mount
  • Circuit:DPDT
  • Switch Function:On-On
  • Current Rating (Amps):0.4VA (AC/DC)
  • Voltage Rating - AC:28 V
  • Voltage Rating - DC:28 V
  • Actuator Type:Locking Lever
  • Actuator Length:16.50mm
  • Illumination:Non-Illuminated
  • Illumination Type, Color:-
  • Illumination Voltage (Nominal):-
  • Termination Style:PC Pin
  • Panel Cutout Dimensions:Circular - 6.50mm Dia
  • Bushing Thread:1/4-40
  • Ingress Protection:IP67 - Dust Tight, Waterproof
  • Features:Epoxy Sealed Terminals
  • Operating Temperature:-30°C ~ 85°C
