DMP56D0UFB-7B Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):50 V
• Current - Continuous Drain (Id) @ 25°C:200mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 4V
• Rds On (Max) @ Id, Vgs:6Ohm @ 100mA, 4V
• Vgs(th) (Max) @ Id:1.2V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:0.58 nC @ 4 V
• Vgs (Max):±8V
• Input Capacitance (Ciss) (Max) @ Vds:50.54 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):425mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:3-X1DFN1006
• Package / Case:3-UFDFN
