BSS139H6906XTSA1 Specifications

• Series:SIPMOS®
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):250 V
• Current - Continuous Drain (Id) @ 25°C:100mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):0V, 10V
• Rds On (Max) @ Id, Vgs:14Ohm @ 100mA, 10V
• Vgs(th) (Max) @ Id:1V @ 56µA
• Gate Charge (Qg) (Max) @ Vgs:3.5 nC @ 5 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:76 pF @ 25 V
• FET Feature:Depletion Mode
• Power Dissipation (Max):360mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PG-SOT23-3-5
• Package / Case:TO-236-3, SC-59, SOT-23-3
