NTMFS4835NT3G Specifications

• Series:-
• Package:Bulk
• Part Status:Obsolete
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:13A (Ta), 130A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 11.5V
• Rds On (Max) @ Id, Vgs:3.5mOhm @ 30A, 10V
• Vgs(th) (Max) @ Id:2.5V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:52 nC @ 11.5 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:3.1 pF @ 12 V
• FET Feature:-
• Power Dissipation (Max):890mW (Ta), 62.5W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:5-DFN (5x6) (8-SOFL)
• Package / Case:8-PowerTDFN, 5 Leads
