DMN2112SN-7 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:1.2A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):1.5V, 4.5V
• Rds On (Max) @ Id, Vgs:100mOhm @ 500mA, 4.5V
• Vgs(th) (Max) @ Id:1.2V @ 1mA
• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±8V
• Input Capacitance (Ciss) (Max) @ Vds:220 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):500mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:SC-59-3
• Package / Case:TO-236-3, SC-59, SOT-23-3
