IPW65R099CFD7AXKSA1 Specifications

• Series:Automotive, AEC-Q101, CoolMOS™ CFD7A
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):650 V
• Current - Continuous Drain (Id) @ 25°C:24A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:99mOhm @ 12.5A, 10V
• Vgs(th) (Max) @ Id:4.5V @ 630µA
• Gate Charge (Qg) (Max) @ Vgs:53 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:2513 pF @ 400 V
• FET Feature:-
• Power Dissipation (Max):127W (Tc)
• Operating Temperature:-40°C ~ 150°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:PG-TO247-3-41
• Package / Case:TO-247-3
