DMP21D5UFB4-7B Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:700mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):1.2V, 5V
• Rds On (Max) @ Id, Vgs:970mOhm @ 100mA, 5V
• Vgs(th) (Max) @ Id:1V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:500 nC @ 4.5 V
• Vgs (Max):±8V
• Input Capacitance (Ciss) (Max) @ Vds:46.1 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):460mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:X2-DFN1006-3
• Package / Case:3-XFDFN
