DMG4800LFG-7 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:7.44A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):4.5V, 10V
• Rds On (Max) @ Id, Vgs:17mOhm @ 9A, 10V
• Vgs(th) (Max) @ Id:1.5V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:9.47 nC @ 5 V
• Vgs (Max):±25V
• Input Capacitance (Ciss) (Max) @ Vds:798 pF @ 10 V
• FET Feature:-
• Power Dissipation (Max):940mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:U-DFN3030-8
• Package / Case:8-PowerUDFN
