SI7111EDN-T1-GE3 Specifications

• Series:TrenchFET® Gen III
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):30 V
• Current - Continuous Drain (Id) @ 25°C:60A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):2.5V, 4.5V
• Rds On (Max) @ Id, Vgs:8.55mOhm @ 15A, 4.5V
• Vgs(th) (Max) @ Id:1.6V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:46 nC @ 2.5 V
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:5860 pF @ 15 V
• FET Feature:-
• Power Dissipation (Max):52W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:PowerPAK® 1212-8
• Package / Case:PowerPAK® 1212-8
