DMN2990UFB-7B Specifications

• Series:Automotive, AEC-Q101
• Package:Tape & Reel (TR)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:780mA (Ta)
• Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
• Rds On (Max) @ Id, Vgs:990mOhm @ 100mA, 4.5V
• Vgs(th) (Max) @ Id:1V @ 250A
• Gate Charge (Qg) (Max) @ Vgs:0.41 nC @ 4.5 V
• Vgs (Max):±8V
• Input Capacitance (Ciss) (Max) @ Vds:31 pF @ 15 V
• FET Feature:-
• Power Dissipation (Max):520mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:X1-DFN1006-3
• Package / Case:3-UFDFN
