DMS2120LFWB-7 Specifications

• Series:-
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:P-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):20 V
• Current - Continuous Drain (Id) @ 25°C:2.9A (Ta)
• Drive Voltage (Max Rds On, Min Rds On):1.8V, 4.5V
• Rds On (Max) @ Id, Vgs:95mOhm @ 2.8A, 4.5V
• Vgs(th) (Max) @ Id:1.3V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:-
• Vgs (Max):±12V
• Input Capacitance (Ciss) (Max) @ Vds:632 pF @ 10 V
• FET Feature:Schottky Diode (Isolated)
• Power Dissipation (Max):1.5W (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:8-DFN3020B (3x2)
• Package / Case:8-VDFN Exposed Pad
