IXFK20N120P Specifications

• Series:HiPerFET™, PolarP2™
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):1200 V
• Current - Continuous Drain (Id) @ 25°C:20A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):10V
• Rds On (Max) @ Id, Vgs:570mOhm @ 10A, 10V
• Vgs(th) (Max) @ Id:6.5V @ 1mA
• Gate Charge (Qg) (Max) @ Vgs:193 nC @ 10 V
• Vgs (Max):±30V
• Input Capacitance (Ciss) (Max) @ Vds:11100 pF @ 25 V
• FET Feature:-
• Power Dissipation (Max):780W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Through Hole
• Supplier Device Package:TO-264AA (IXFK)
• Package / Case:TO-264-3, TO-264AA
