IXTA08N100D2HV Specifications

• Series:-
• Package:Tube
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):1000 V
• Current - Continuous Drain (Id) @ 25°C:800mA (Tj)
• Drive Voltage (Max Rds On, Min Rds On):0V
• Rds On (Max) @ Id, Vgs:21Ohm @ 400mA, 0V
• Vgs(th) (Max) @ Id:4V @ 25µA
• Gate Charge (Qg) (Max) @ Vgs:14.6 nC @ 5 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:325 pF @ 25 V
• FET Feature:Depletion Mode
• Power Dissipation (Max):60W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:TO-263HV
• Package / Case:TO-263-3, D²Pak (2 Leads + Tab), TO-263AB
