AOUS66616 Specifications

• Series:AlphaSGT™
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• FET Type:N-Channel
• Technology:MOSFET (Metal Oxide)
• Drain to Source Voltage (Vdss):60 V
• Current - Continuous Drain (Id) @ 25°C:33A (Ta), 92A (Tc)
• Drive Voltage (Max Rds On, Min Rds On):6V, 10V
• Rds On (Max) @ Id, Vgs:3.3mOhm @ 20A, 10V
• Vgs(th) (Max) @ Id:3.4V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:60 nC @ 10 V
• Vgs (Max):±20V
• Input Capacitance (Ciss) (Max) @ Vds:2870 pF @ 30 V
• FET Feature:-
• Power Dissipation (Max):6.2W (Ta), 92.5W (Tc)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Supplier Device Package:UltraSO-8™
• Package / Case:3-PowerSMD, Flat Leads
