SGS23N60UFDTU

Image is for reference, please contact us to get the real picture

Manufacturer Part
SGS23N60UFDTU
Manufacturer
Sanyo Semiconductor/ON Semiconductor
Description
IGBT 600V 23A 73W TO220F
Category
Discrete Semiconductor Products
Family
Transistors - IGBTs - Single
Series
-
In Stock
3000
Datasheets
-

SGS23N60UFDTU Specifications

  • Series:-
  • Package:Tube
  • Part Status:Last Time Buy
  • IGBT Type:-
  • Voltage - Collector Emitter Breakdown (Max):600 V
  • Current - Collector (Ic) (Max):23 A
  • Current - Collector Pulsed (Icm):92 A
  • Vce(on) (Max) @ Vge, Ic:2.6V @ 15V, 12A
  • Power - Max:73 W
  • Switching Energy:115µJ (on), 135µJ (off)
  • Input Type:Standard
  • Gate Charge:49 nC
  • Td (on/off) @ 25°C:17ns/60ns
  • Test Condition:300V, 12A, 23Ohm, 15V
  • Reverse Recovery Time (trr):60 ns
  • Operating Temperature:-55°C ~ 150°C (TJ)
  • Mounting Type:Through Hole
  • Package / Case:TO-220-3 Full Pack
  • Supplier Device Package:TO-220F
