DMC2038LVTQ-7 Specifications

• Series:Automotive, AEC-Q101
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Not For New Designs
• FET Type:N and P-Channel Complementary
• FET Feature:Logic Level Gate, 1.8V Drive
• Drain to Source Voltage (Vdss):20V
• Current - Continuous Drain (Id) @ 25°C:3.7A (Ta), 2.6A (Ta)
• Rds On (Max) @ Id, Vgs:35mOhm @ 4A, 4.5V, 74mOhm @ 3A, 4.5V
• Vgs(th) (Max) @ Id:1V @ 250µA
• Gate Charge (Qg) (Max) @ Vgs:5.7nC @ 4.5V, 10nC @ 4.5V
• Input Capacitance (Ciss) (Max) @ Vds:530pF @ 10V, 705pF @ 10V
• Power - Max:800mW (Ta)
• Operating Temperature:-55°C ~ 150°C (TJ)
• Mounting Type:Surface Mount
• Package / Case:SOT-23-6 Thin, TSOT-23-6
• Supplier Device Package:TSOT-26
