1-776163-6

Image is for reference, please contact us to get the real picture

Manufacturer Part
1-776163-6
Manufacturer
TE Connectivity AMP Connectors
Description
CONN HEADER R/A 35POS 4MM
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Male Pins
Series
-
In Stock
604
Datasheets
-

1-776163-6 Specifications

  • Series:AMPSEAL
  • Package:Bulk
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Pin
  • Pitch - Mating:0.157" (4.00mm)
  • Number of Positions:35
  • Number of Rows:3
  • Row Spacing - Mating:0.157" (4.00mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Panel Mount, Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Locking Ramp
  • Contact Length - Mating:-
  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:-
  • Contact Shape:Circular
  • Contact Finish - Mating:Gold-Palladium
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:-
  • Contact Material:Brass
  • Insulation Material:Polybutylene Terephthalate (PBT), Glass Filled
  • Features:Board Guide, Sealed
  • Operating Temperature:-40°C ~ 125°C
  • Ingress Protection:-
  • Material Flammability Rating:-
  • Insulation Color:Orange
  • Current Rating (Amps):Varies by Wire Gauge
  • Voltage Rating:250VAC
