2026560021 Specifications

• Series:Pico-EZmate Slim 202656
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Connector Type:Plug
• Contact Type:Tab
• Pitch - Mating:0.047" (1.20mm)
• Number of Positions:2
• Number of Rows:1
• Row Spacing - Mating:-
• Number of Positions Loaded:All
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 3 Wall
• Mounting Type:Surface Mount
• Termination:Solder
• Fastening Type:Friction Lock
• Contact Length - Mating:0.042" (1.06mm)
• Contact Length - Post:-
• Overall Contact Length:-
• Insulation Height:0.047" (1.20mm)
• Contact Shape:Rectangular
• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:3.90µin (0.099µm)
• Contact Finish - Post:Gold
• Contact Material:Copper Alloy
• Insulation Material:Polyamide (PA), Nylon
• Features:Solder Retention
• Operating Temperature:-25°C ~ 85°C
• Ingress Protection:-
• Material Flammability Rating:UL94 V-0
• Insulation Color:Black
• Current Rating (Amps):1.5A
• Voltage Rating:50V
