828801-1

Image is for reference, please contact us to get the real picture

Manufacturer Part
828801-1
Manufacturer
TE Connectivity AMP Connectors
Description
CONN HEADER R/A 4POS 5MM
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Male Pins
Series
-
In Stock
25
Datasheets
-

828801-1 Specifications

  • Series:Junior Power Timer
  • Package:Tray
  • Part Status:Active
  • Connector Type:Plug
  • Contact Type:Tab
  • Pitch - Mating:0.197" (5.00mm)
  • Number of Positions:4
  • Number of Rows:2
  • Row Spacing - Mating:0.197" (5.00mm)
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:-
  • Contact Length - Mating:0.366" (9.30mm)
  • Contact Length - Post:0.138" (3.50mm)
  • Overall Contact Length:-
  • Insulation Height:0.748" (19.00mm)
  • Contact Shape:Rectangular
  • Contact Finish - Mating:Tin
  • Contact Finish Thickness - Mating:-
  • Contact Finish - Post:Tin
  • Contact Material:Brass
  • Insulation Material:Polyamide (PA66), Nylon 6/6
  • Features:Mounting Flange
  • Operating Temperature:-55°C ~ 105°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-2
  • Insulation Color:Black
  • Current Rating (Amps):-
  • Voltage Rating:-
