10140952-102LF Specifications

• Series:Verio™
• Package:Tape & Reel (TR)Cut Tape (CT)
• Part Status:Active
• Connector Type:Plug
• Contact Type:Male Blade
• Pitch - Mating:0.248" (6.30mm)
• Number of Positions:4 (Power)
• Number of Rows:2
• Row Spacing - Mating:0.224" (5.70mm)
• Number of Positions Loaded:3
• Style:Board to Cable/Wire
• Shrouding:Shrouded - 4 Wall
• Mounting Type:Through Hole, Right Angle
• Termination:Solder
• Fastening Type:Latch Holder
• Contact Length - Mating:0.295" (7.49mm)
• Contact Length - Post:0.106" (2.69mm)
• Overall Contact Length:-
• Insulation Height:0.492" (12.50mm)
• Contact Shape:Rectangular
• Contact Finish - Mating:Tin
• Contact Finish Thickness - Mating:-
• Contact Finish - Post:Tin
• Contact Material:Copper Alloy
• Insulation Material:Liquid Crystal Polymer (LCP), Glass Filled
• Features:Board Guide
• Operating Temperature:-55°C ~ 85°C
• Ingress Protection:IP67
• Material Flammability Rating:UL94 V-0
• Insulation Color:-
• Current Rating (Amps):-
• Voltage Rating:-
