DF50-20DP-1H(51)

Image is for reference, please contact us to get the real picture

Manufacturer Part
DF50-20DP-1H(51)
Manufacturer
Hirose
Description
CONN HEADER SMD R/A 20POS 1MM
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Male Pins
Series
-
In Stock
570
Datasheets
-

DF50-20DP-1H(51) Specifications

  • Series:DF50
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Connector Type:Header
  • Contact Type:Male Blade
  • Pitch - Mating:0.039" (1.00mm)
  • Number of Positions:20
  • Number of Rows:2
  • Row Spacing - Mating:-
  • Number of Positions Loaded:All
  • Style:Board to Cable/Wire
  • Shrouding:Shrouded - 4 Wall
  • Mounting Type:Surface Mount, Right Angle
  • Termination:Solder
  • Fastening Type:Latch Lock
  • Contact Length - Mating:-
  • Contact Length - Post:-
  • Overall Contact Length:-
  • Insulation Height:0.354" (9.00mm)
  • Contact Shape:-
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:2.00µin (0.051µm)
  • Contact Finish - Post:Gold
  • Contact Material:Brass
  • Insulation Material:Polyester
  • Features:Solder Retention
  • Operating Temperature:-35°C ~ 85°C
  • Ingress Protection:-
  • Material Flammability Rating:UL94 V-0
  • Insulation Color:Black
  • Current Rating (Amps):1A
  • Voltage Rating:100V
