HLE-109-02-S-DV-BE-LC-K

Image is for reference, please contact us to get the real picture

Manufacturer Part
HLE-109-02-S-DV-BE-LC-K
Manufacturer
Samtec, Inc.
Description
CONN RCPT 18POS 0.1 GOLD SMD
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
110
Datasheets
-

HLE-109-02-S-DV-BE-LC-K Specifications

  • Series:HLE
  • Package:Tube
  • Part Status:Active
  • Connector Type:Receptacle, Bottom Entry
  • Contact Type:Female Socket
  • Style:Board to Board
  • Number of Positions:18
  • Number of Positions Loaded:All
  • Pitch - Mating:0.100" (2.54mm)
  • Number of Rows:2
  • Row Spacing - Mating:0.100" (2.54mm)
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:30.0µin (0.76µm)
  • Insulation Color:Black
  • Insulation Height:0.144" (3.66mm)
  • Contact Length - Post:-
  • Operating Temperature:-55°C ~ 125°C
  • Material Flammability Rating:-
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:-
  • Ingress Protection:-
  • Features:Board Lock, Pick and Place
  • Current Rating (Amps):4.1A per Contact
  • Voltage Rating:400VAC
