0872641652

Image is for reference, please contact us to get the real picture

Manufacturer Part
0872641652
Manufacturer
Woodhead - Molex
Description
CONN RCPT 16P 0.079 GOLD PCB R/A
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
99
Datasheets
-

0872641652 Specifications

  • Series:Milli-Grid 87264
  • Package:Tube
  • Part Status:Active
  • Connector Type:Receptacle
  • Contact Type:Female Socket
  • Style:Board to Board or Cable
  • Number of Positions:16
  • Number of Positions Loaded:All
  • Pitch - Mating:0.079" (2.00mm)
  • Number of Rows:2
  • Row Spacing - Mating:0.079" (2.00mm)
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:15.0µin (0.38µm)
  • Insulation Color:Black
  • Insulation Height:0.157" (4.00mm)
  • Contact Length - Post:0.100" (2.54mm)
  • Operating Temperature:-55°C ~ 105°C
  • Material Flammability Rating:-
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:-
  • Ingress Protection:-
  • Features:-
  • Current Rating (Amps):1A
  • Voltage Rating:125VAC
