FX30B-4S-3.81DS

Image is for reference, please contact us to get the real picture

Manufacturer Part
FX30B-4S-3.81DS
Manufacturer
Hirose
Description
CONN RCPT 4POS 0.15 GOLD PCB R/A
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
33
Datasheets
-

FX30B-4S-3.81DS Specifications

  • Series:FunctionMax™ FX30B
  • Package:Tray
  • Part Status:Active
  • Connector Type:Receptacle
  • Contact Type:Female Blade Socket
  • Style:Board to Board
  • Number of Positions:4
  • Number of Positions Loaded:All
  • Pitch - Mating:0.150" (3.81mm)
  • Number of Rows:1
  • Row Spacing - Mating:-
  • Mounting Type:Through Hole, Right Angle
  • Termination:Solder
  • Fastening Type:Latch Holder
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:3.90µin (0.099µm)
  • Insulation Color:Black
  • Insulation Height:0.433" (11.00mm)
  • Contact Length - Post:0.130" (3.30mm)
  • Operating Temperature:-55°C ~ 105°C
  • Material Flammability Rating:UL94 V-0
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:-
  • Ingress Protection:-
  • Features:Board Guide, Board Lock
  • Current Rating (Amps):13A
  • Voltage Rating:250V
