ESMC-F-16-SGS-SMT-A-PP-T/R

Image is for reference, please contact us to get the real picture

Manufacturer Part
ESMC-F-16-SGS-SMT-A-PP-T/R
Manufacturer
Adam Tech
Description
CONN RCPT VERT SMT 16POS 1.27MM
Category
Connectors, Interconnects
Family
Rectangular Connectors - Headers, Receptacles, Female Sockets
Series
-
In Stock
504
Datasheets
-

ESMC-F-16-SGS-SMT-A-PP-T/R Specifications

  • Series:ESMC
  • Package:Tape & Reel (TR)Cut Tape (CT)
  • Part Status:Active
  • Connector Type:Receptacle
  • Contact Type:Female Socket
  • Style:Board to Board
  • Number of Positions:16
  • Number of Positions Loaded:All
  • Pitch - Mating:0.050" (1.27mm)
  • Number of Rows:2
  • Row Spacing - Mating:0.050" (1.27mm)
  • Mounting Type:Surface Mount
  • Termination:Solder
  • Fastening Type:Push-Pull
  • Contact Finish - Mating:Gold
  • Contact Finish Thickness - Mating:Flash
  • Insulation Color:Black
  • Insulation Height:0.246" (6.25mm)
  • Contact Length - Post:-
  • Operating Temperature:-55°C ~ 125°C
  • Material Flammability Rating:UL94 V-0
  • Contact Finish - Post:Tin
  • Mated Stacking Heights:8mm, 9.5mm, 11.1mm
  • Ingress Protection:-
  • Features:Board Guide, Pick and Place, Solder Retention
  • Current Rating (Amps):1.2A
  • Voltage Rating:-
