8540-4500PL Specifications

• Series:8500
• Package:Bulk
• Part Status:Active
• Connector Type:Receptacle
• Contact Type:Female Socket
• Style:Board to Board or Cable
• Number of Positions:40
• Number of Positions Loaded:All
• Pitch - Mating:0.100" (2.54mm)
• Number of Rows:2
• Row Spacing - Mating:0.100" (2.54mm)
• Mounting Type:Through Hole
• Termination:Kinked Pin, Solder
• Fastening Type:Push-Pull
• Contact Finish - Mating:Gold
• Contact Finish Thickness - Mating:12.0µin (0.30µm)
• Insulation Color:Gray
• Insulation Height:0.425" (10.80mm)
• Contact Length - Post:0.110" (2.79mm)
• Operating Temperature:-55°C ~ 105°C
• Material Flammability Rating:UL94 V-0
• Contact Finish - Post:Gold
• Mated Stacking Heights:-
• Ingress Protection:-
• Features:Polarizing Key
• Current Rating (Amps):1A
• Voltage Rating:1000V
