1688100000

Image is for reference, please contact us to get the real picture

Manufacturer Part
1688100000
Manufacturer
Weidmuller
Description
TERM BLOCK PLUG 24POS STR 3.5MM
Category
Connectors, Interconnects
Family
Terminal Blocks - Headers, Plugs and Sockets
Series
-
In Stock
18126
Datasheets
-

1688100000 Specifications

  • Series:Omnimate BL
  • Package:Bulk
  • Part Status:Active
  • Type:Plug, Female Sockets
  • Number of Positions:24
  • Positions Per Level:24
  • Number of Levels:1
  • Pitch:0.138" (3.50mm)
  • Header Orientation:-
  • Plug Wire Entry:180°
  • Termination Style:Screw - Clamping Yoke (Tension Sleeve)
  • Mounting Type:Free Hanging (In-Line)
  • Current - IEC:17A
  • Voltage - IEC:320 V
  • Current - UL:10 A
  • Voltage - UL:300 V
  • Wire Gauge or Range - AWG:14-28 AWG
  • Wire Gauge or Range - mm²:0.2-1.5mm²
  • Color:Black
  • Operating Temperature:-50°C ~ 100°C
  • Contact Mating Finish:Tin
  • Features:Ejector Latches
