1357940000

Image is for reference, please contact us to get the real picture

Manufacturer Part
1357940000
Manufacturer
Weidmuller
Description
TERM BLOCK HDR 24POS 90DEG 3.5MM
Category
Connectors, Interconnects
Family
Terminal Blocks - Headers, Plugs and Sockets
Series
-
In Stock
40
Datasheets
-

1357940000 Specifications

  • Series:Omnimate S2C
  • Package:Bulk
  • Part Status:Active
  • Type:Header, Male Pins, Shrouded (4 Side), Stacked
  • Number of Positions:24
  • Positions Per Level:12, 12
  • Number of Levels:2, 2
  • Pitch:0.138" (3.50mm)
  • Header Orientation:90°, Right Angle
  • Plug Wire Entry:-
  • Termination Style:Solder
  • Mounting Type:Through Hole
  • Current - IEC:7.9A
  • Voltage - IEC:200 V
  • Current - UL:9.5 A
  • Voltage - UL:150 V
  • Wire Gauge or Range - AWG:-
  • Wire Gauge or Range - mm²:-
  • Color:Black
  • Operating Temperature:-50°C ~ 120°C
  • Contact Mating Finish:Tin
  • Features:Mating Flange, Solder Retention
